InLine® I/O Card 4x USB 3.0 (2-External

port + Dual Port Internal Connector), PCIe,

InLine®, incl. low-profile bracket

Art.-No.: 76666B

EAN: 4043718189496

4-port USB 3.0 interface card with an internal 19-pin. Mainboardaschluss and external 2x

USB 3.0 A connectors. The additional power is supplied via a SATA power connector

conform to the x1 PCI Express specifications Rev. 2.0

backward compatible to the PCI Express bus Spec Rev. 1.0a

Supports data rates up to 5Gb/s

Fully plug and Play compatible

Supports Windows 7 / Vista / XP / 2008 (all 32/64-bit)

compliant with USB 3.0 specification Rev. 1.0, backward compatible with USB 2.0

Supports data transfer rates up to 5Gb/s

External 2x USB A female, internally standardized USB 3.0 mainboard connection

(19pin.)

SATA power connection internally (15pol.)

including low-profile bracket
